15.6″ Android Touch Screen Display – SIN-M01X156

15.6″ Android Touch Screen Display – SIN-M01X156

The SIN-M01X156 15.6-inch Android touch screen is a professional-grade digital signage display powered by RK3568 quad-core processor with Android 11 operating system. Featuring 10-point capacitive touch technology and 1920×1080 Full HD resolution, this display delivers exceptional visual performance for commercial applications.

Equipped with a built-in RFID reader supporting MIFARE, 14443A, and 15693 protocols, this touch screen is ideal for electronic bulletin board and access control applications. The 2MP wide dynamic camera supports optional facial recognition upgrade.

Core Parameters

• Display: 15.6 inch TFT LCD, 1920×1080 Full HD
• Touch: 10-point capacitive (G+G), response <8ms
• Processor: RK3568 Quad-core, 2.0GHz
• OS: Android 11
• Memory: 2GB DDR + 16GB Flash
• Camera: 2MP Wide Dynamic (Optional 5MP)

Applications

• Digital signage displays
• Electronic bulletin boards for schools and offices
• Smart retail terminals
• Access control systems
• Information kiosks

Specifications

• Display Size: 15.6 inches
• Resolution: 1920×1080 Full HD
• Aspect Ratio: 16:9
• Brightness: 300cd/m²
• Contrast Ratio: 1000:1
• Touch Screen: G+G Projective Capacitive, 10-point
• Response Time: 14-25ms
• Armor Glass: Moss 7th Grade Tempered
• RFID Protocols: 14443A, 15693, MIFARE S50/S70
• Reading Distance: 0-80mm
• USB: 2× USB ports
• Network: 1× RJ45, WiFi
• Power Input: DC 12V / AC 220V
• Power Consumption: <30W (Working), ≤0.5W (Standby)
• Working Temp: 0°C ~ +50°C
• Installation: Wall-mounted

Get a Quote
Interested in this 15.6-inch Android touch screen? Contact us for a quote and customized solutions for your digital signage or electronic bulletin board project. We also offer OEM/ODM services for bulk orders.
